Lavor Free Evo 50E Floor Scrubber

The Lavor Free Evo 50E Floor Scrubber is a professional model that combines high-performance cleaning power with the uninterrupted energy of a cable-operated system. Operating on 230 V / 50 Hz, the machine provides up to 2000 m²/h theoretical cleaning capacity. With a 500 mm brush width, 800 mm suction path, and 44-liter clean water and 50-liter dirty water tanks, it ensures long and consistent cleaning cycles. The mechanical traction system offers easy control, while its 115 kg weight applies optimal pressure to the floor for deep, effective cleaning.

Technical Performance and Features

Cabled Power Supply and Stable Performance

The 230 V power system allows continuous cleaning without the need for battery charging. The cable-operated structure ensures stable performance even during long shifts. Direct and consistent power transfer increases energy efficiency, offering an advantage especially in facilities with continuous cleaning operations.

Brush and Vacuum System

The 550 W brush motor delivers high-speed cleaning across a 500 mm width, effectively removing oil, dirt, and residue from surfaces. The 1000 W vacuum motor works together with an 800 mm suction width to instantly collect detergent water, leaving the surface dry and eliminating slip hazards. The solenoid valve–controlled water output optimizes water and chemical usage, ensuring consistent and economical cleaning.

Tank Capacity and Body Balance

With 44 liters of clean water and 50 liters of dirty water capacity, the machine is well-suited for long working periods. The tanks are made from durable materials resistant to impacts, chemicals, and heat. Its 115 kg weight applies uniform pressure on the brush for more efficient cleaning.

Mechanical Traction System

The mechanical traction system allows the operator to maneuver the machine with minimal effort. This system requires very little maintenance and reduces overall operating costs. Its optimized center of gravity enables safe and stable movement, even during tight turns.

Usage Instructions and Recommendations

Preparation

Fill the clean water tank with a properly mixed detergent solution. Ensure the electrical connection is grounded and safe. Plan the cable route to prevent tripping or tension during operation. Check the brush and squeegee blades before starting.

Cleaning Application

Start the machine, lower the brush, and activate the scrub-and-vacuum mode. Move forward at a steady pace, overlapping each pass by about 30%. Reduce speed in heavily soiled areas to increase brush contact and improve cleaning. Ensure the squeegee makes full contact with the floor during turns.

Rinsing and Shutdown

After cleaning, make a final vacuum pass to remove any remaining moisture. Empty the dirty water tank and rinse the tank and hoses with clean water. Remove the brush and squeegee blades, wash them, and let them dry. Coil the cable neatly and store the machine in an upright position.

Maintenance and Safety

Regularly check the cable, plug, and connections. Keep filters and the water system clean. Do not allow chemical residues to remain in the tanks. Replace worn squeegee blades to prevent streaking. For long-term storage, keep the machine in a dry environment.

Application Areas

The Lavor Free Evo 50E is designed for hotels, hospitals, schools, public buildings, production facilities, and large office areas. Its cable-powered system offers stable, uninterrupted performance, ideal for environments requiring long, continuous cleaning. With quiet and low-vibration operation, it can be used safely in high-traffic areas.

The Lavor Free Evo 50E Floor Scrubber—with its 230 V power system, 500 mm brush, 800 mm suction path, and 2000 m²/h capacity—combines the strength of a cable-powered system with a durable body design. It is an ideal choice for businesses seeking stable power, economical operation, and professional cleaning results during extended cleaning cycles.
